Motrec MP-500
  • + Expand All
  • - Close All
  • SpecificationsTable
    6 pass. 8 pass. 10 pass. 11 pass. Wheel
    chair
    Powertrain
    Energy
    Voltage 48V 48V 48V 48V
    Battery Eight 6V-220AH batteries Eight 6V-244AH batteries Eight 6V-220AH batteries Eight 6V-220AH batteries Eight 6V-244AH batteries
    Charger 25 amp, built-in, automatic High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC
    Chassis
    Brakes Rear hydraulic brakes, 11", regenerative braking 4 wheels 11", regenerative braking Rear hydraulic brakes, 11", regenerative braking Rear hydraulic brakes, 11", regenerative braking 4 wheels 11", regenerative braking
    Seats Two bucket seats on slide adjusters Two bucket seats on slide adjusters, plus 3 bench type Two bucket seats on slide adjusters Two bucket seats on slide adjusters Two bucket seats on slide adjusters, plus 3 bench type and wheel chair access ramp
    Equipment
    Accessories Horn Horn, Bolt-on Front Bumper, DC/DC converter to equalize battery cells Horn, Bolt-on Front Bumper Horn, Bolt-on Front Bumper Horn, Bolt-on Front Bumper, DC/DC converter to equalize battery cells
    Safety Deadman seat switch Deadman seat switch, reverse alarm, seat belts Deadman seat switch, reverse alarm, seat belts Deadman seat switch Deadman seat switch, reverse alarm, seat belts
  • Wheels5.7x8 LRC pneumatic tires
  • Body14-G diamond-plate steel body, tubular frame
  • TransmissionGoodyear Eagle Synchronous drive
  • Motor15 hp shunt motor
  • Drive AxleDifferential with automotive ring gear
  • SteeringAutomotive steering wheel
  • ControllerElectronic speed controller
  • IndicatorsBattery status indicator
  • SuspensionDual leaf springs on front and rear
  • LightsLED dual headlights & tail/brake lights
