• Platform Dimension A2 ft 6 in. / 0.76 m
  • Platform Capacity - Extension250 lb / 113.40 kg
  • Charger20 amp automatic
  • Ground Clearance4 in. / 0.09 m
  • Platform Railing Height3 ft 7 in. / 1.1 m
  • Capacity - Hydraulic Reservoir1.3 gal. / 4.73 L
  • Platform Height - Lowered4 ft 1 in. / 1.23 m
  • Lift Time33 sec.
  • Turning Radius - Outside6 ft 9 in. / 2.06 m
  • Platform Height25 ft 6 in. / 7.77 m
  • Machine Weight4635 lb / 2102.40 kg
  • BrakesElectric, Friction
  • Machine Height7 ft 8 in. / 2.33 m
  • Batteries4 x 6V, 220 amp-hour
  • Machine Width2 ft 8 in. / 0.81 m
  • Platform Extension Length3 ft / 0.9 m
  • Platform Dimension B7 ft 7 in. / 2.3 m
  • Turning Radius - Inside0 in. / 0 m
  • Lower Time37 sec.
  • Platform Capacity - Restricted800 lb / 362.87 kg
  • Drive Speed - Platform Elevated0.5 mph / 0.80 km/h
  • Hydraulic PumpFixed Displacement Gear
  • Platform Capacity - Unrestricted500 lb / 226.80 kg
  • Gradeability25 %
  • Maximum Ground Bearing Pressure90 psi / 6.30 Kg/cm2
  • Tire Size16 X 5 in
  • Drive System24V Electric
  • Drive Speed - Platform Lowered2.8 mph / 4.43 km/h
  • Machine Height - Rails Folded6 ft 5 in. / 1.94 m
  • Working Height31 ft 6 in. / 9.6 m
  • Wheelbase6 ft 2 in. / 1.88 m
