JLG 400S HC3
Aerial
Equipment Features
- 12V-DC Auxiliary Power
- 110V-AC Receptacle in the Platform
- ClearSky Smart Fleet™ Hardware (CS550)
| Auxiliary Power | 12 Volts DC |
|---|---|
| Capacity - Fuel Tank | 22 gal. / 83.28 L |
| Capacity - Hydraulic Reservoir | 36 gal. / 136.27 L |
| Drive Speed - 4WD | 4.5 mph |
| Engine Type - Diesel | Deutz D2.9L4 Tier 4 Final 49 hp |
| Gradeability | 45% |
| Horizontal Outreach | 33 ft 7 in |
| Machine Weight | 15,040 lbs |
| Maximum Ground Bearing Pressure | 65 psi |
| Platform Capacity - Restricted | 750/1,000 lbs |
| Platform Capacity - Unrestricted | 660 lbs |
| Platform Height | 40 ft / 12.19 m |
| Swing | 360 Degrees Continuous |
| Turning Radius - Outside | 15 ft 8 in |
- USB-A and USB-C Charger
| Equipment Document | View Link |
|---|
Key Specs
- Platform Height: 40 ft
- Platform Capacity – Restricted: 750/1000 lb
- Platform Capacity – Unrestricted: 660 lb
- Horizontal Outreach: 33 ft 7 in
- Drive Speed: 4.25 mph
Key Features
- Utilizes three working zones for enhanced capacity; up to three workers and tools can fit onto the platform.
- Delivers a zero calibration automatic load sensing system that eliminates the need to use external weights to calibrate the machine.
- Utilizes an upgraded light panel that is more visible in the sun, and a chassis tilt alarm that alerts the operator when the machine is on a slope that exceeds 5 Degrees.
- Complies with A92.20 ANSI regulations, achieving the highest standards.
