JLG 19AMI
Aerial
Key Specs
- Platform Height: 19 ft 4 in. / 5.89 m
- Machine Width: 2 ft 10 in. / 0.86 m
Key Features
- Most rigid mast in the industry for operator comfort and stability
- Six-wheel design for improved maneuverability
- Long battery duty cycles and an automatic charger for more productivity
- No outriggers
| Ground Entry Height | 1 ft 7 in. / 0.48 m |
|---|---|
| Machine Height | 6 ft 6 in. / 1.98 m |
| Machine Length | 4 ft 5 in. / 1.33 m |
| Machine Weight-DC | 1130 lb / 512.56 kg |
| Machine Width | 2 ft 10 in. / 0.86 m |
| Maximum Lift Height | 19.3 ft / 5.89 m |
| Outriggers or Stabilizers | No |
| Platform Capacity | 350 lb / 158.76 kg |
| Platform Dimension A | 2 ft 2 in. / 0.66 m |
| Platform Dimension B | 2 ft 4 in. / 0.71 m |
| Platform Height | 19 ft 4 in. / 5.89 m |
| Wheel Size - Front Caster | 6 x 2" |
| Wheel Size - Rear | 10 x 2" |
| Working Height | 25 ft / 7.62 m |
- Long battery duty cycles and an automatic charger for more productivity
- Most rigid mast in the industry for operator comfort and stability
- No outriggers
- Six-wheel design for improved maneuverability
