  • Specifications Table

    24V

    36V

    Passengers

    1

    1

    Load Capacity

    500 lbs.

    500 lbs.

    Towing Capacity

    2,000 lbs.

    5,000 lbs.

    Speed

    8 mph

    8 mph

    Turning Radius

    86"

    86"

    POWERTRAIN

    Motor

    6 hp shunt motor

    10 hp shunt motor

    Drive Axle

    Helical gear differential

    Helical gear differential

    Transmission

    Direct drive

    Direct drive

    Controller

    SEPEX Electronic speed controller

    SEPEX Electronic speed controller

    ENERGY

    Voltage

    24V

    36V

    Battery

    Four 6V-225AH batteries

    Six 6V-225AH batteries

    Charger

    High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic.

    High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC

    CHASSIS

    Body

    All-steel unibody construction. Powder Coating.

    All-steel unibody construction. Powder Coating.

    Suspension

    Dual coil springs and shock absorber on rear

    Dual coil springs and shock absorber on rear

    Brakes

    Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake, regenerative braking

    Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake, regenerative braking

    Wheels

    4.8x8 LRB pneumatic tires

    4.8x8 LRB pneumatic tires

    Steering

    Automotive Steering Wheel

    Automotive Steering Wheel

    Seats

    Bucket seat on slide adjusters

    Bucket seat on slide adjusters

    EQUIPMENT

    Lights

    LED headlight & tail/brake light

    LED headlight & tail/brake light

    Indicators

    Battery status indicator

    Battery status indicator

    Accessories

    Bolt-on bumpers and rear wheel guards, 12V accessories

    Bolt-on bumpers and rear wheel guards, 24V accessories to equalize cells and extend battery life.

    Safety

    Reverse alarm, deadman seat switch, horn

    Reverse alarm, deadman seat switch, horn

    VEHICLE

    Weight

    Height

    45"

    45"

    Length

    86"

    86"

    Width

    30"

    30"

    Wheel Base

    63"

    63"

    DECK

    Deck Height

    42"

    42"

    Deck Length

    31"

    31"

    Deck Width

    30"

    30"

    BATTERY

    Battery Weight

    Battery Height

    Battery Length

    Battery Width
