Hyster H80-120FT
Forklifts
Tough, Dependable and Efficient
Designed for indoor and outdoor use, the Fortis® H80-120FT lift truck series offers a versatile solution for multiple applications such as brick/block, precast/concrete, recycling and lumber.
To exceed applications requirements, the series offers various powertrain combinations, a productivity enhancing ergonomic operator compartment as well as additional cooling and efficiency options.
| Capacity | 8,000 - 12,000 lbs |
|---|---|
| Max Height | 310 |
| Max Weight | 12000 lbs |
| Series Title | H80-120FT |
| Type | 4 Wheel Pneumatic Tire |
| Weight | lbs |
- Advanced transmissions are built for durability and patented controllability, while extending tire and brake life up to 50%
- Combi-cooler contains an individual transmission oil cooler to maximize heat dissipation
- Ergonomic operator compartment includes optimized step height with non-slip tread, soft touch contoured hand grip and infinitely adjustable steer column
- Full venting package draws air into the engine compartment from higher on the truck to enhance airflow and avoid radiator clogging
- Fully sealed wet disc brakes virtually eliminate brake maintenance and often last the life of the truck
- On-demand hydraulic system featuring TouchPoint mini-lever controls pumps oil only when required, reducing fuel consumption
- All engine configurations feature Hyster® Variable Power Technology™, selectable performance modes that can be adjusted to maximize productivity or fuel economy to fit specific application requirements
- On-demand cooling system matches cooling fan speed to engine temperature, maintaining optimum engine and transmission temperatures, virtually eliminating the possibility of overheating
- Powertrain combinations include Kubota 3.8L LPG/ Dual Fuel/ DOC diesel
| Model | Load Capacity (lbs) | Engine | Transmission | Maximum Travel Speed (mph) | Maximum Lift Speed (ft/min) |
|---|---|---|---|---|---|
| H80FT | 8000 | Kubota 3.8L LPG, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel | Electronically Controlled Powershift 1 Speed, Electronically Controlled Powershift 2 Speed, DuraMatch Electronic 1 Speed, DuraMatch Electronic 2 Speed | 16 | 125 |
| H90FT | 9000 | Kubota 3.8L LPG, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel | Electronically Controlled Powershift 1 Speed, Electronically Controlled Powershift 2 Speed, DuraMatch Electronic 1 Speed, DuraMatch Electronic 2 Speed | 16 | 125 |
| H100FT | 10000 | Kubota 3.8L LPG, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel | Electronically Controlled Powershift 2 Speed, Duramatch Electronic 2 Speed | 14.8 | 102 |
| H110FT | 11000 | Kubota 3.8L LPG, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel | Electronic Controlled Powershift 2 Speed, Duramatch Electronic 2 Speed | 14.7 | 102 |
| H120FT | 12000 | Kubota 3.8L LPG, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel | Electronically Controlled Powershift 2 Speed, Duramatch Electronic 2 Speed | 14.7 | 102 |
