  • ELECTRICAL SYSTEMS
    Controller

    350W Controller

    Motor

    4kW Motor

    Charger

    ICON 48V Onboard Charging System with Body Mounted Charge Indicator

    Batteries

    (8) 6V Sealed Maintenance Free AGM

  • Dash ComponentsForward/Neutral/Reverse Switch, USB and 12V Plugs, Cubby Storage, Multiple Cup Holders, Key Switch, Instrumentation Cluster
  • RoofInnovative air deflecting design with full high-strength aluminum frame
  • FloorUnique PP Molded for extra toughness and durability
  • Rear SuspensionSolid Axle Coil Over Shock and Stabilizing Bar
  • Safety RestraintSide Hip Restraint & Retractable Seat Belts
  • Capacity4 People
  • Weight1300 lbs
  • Overall Dimensions108inx49inx72in
  • BodyInjection Molded Thermoplastic that is both stylish and resilient to outside damage
  • Drivetrain14:1 High Speed Rear Axle
  • WindshieldFoldable Acrylic
  • Wheels8" Machined Face Steel with powder coated accents
  • InstrumentationFully Integrated Digital Instrument Cluster
  • Lighting and SignalsSingle Combination Switch for Halogen Projector, LED Signal Lights, Taillights, and Horn
  • MirrorsFully Adjustable and Foldable
  • Front SuspensionMacpherson Style Fully Independent Coil Over Shock with Camber Adjustment.
  • Tires23x10.5-12 4 Ply Nylon Cord
  • ChassisTubular Powder Coated Steel Frame
  • SeatsMarine Grade Vinyl, Custom Stitched Panel, Black. Fold Flat Rear Seat for Hauling.
  • SteeringSelf-Adjusting Double-Ended Rack and Pinion
  • Braking SystemMechanical Rear Drum Brake
  • ColorsAlpine White Metallic, Champagne Metallic, Forest Green Metallic, Raven Black Metallic
