Motrec MP-250
Personnel Carriers
It’s no surprise the competition envies our original design. This agile and versatile personnel carrier has it all: A narrow deck, four wheels for greater stability on rough terrain, powerful motor, rugged automotive differential and larger self-adjusting drum brakes, all-steel unibody construction, bolt-on front bumper and side bar protection, easy-to-access under-seat battery compartment… The list keeps going. It can also pull up to 6,000 lbs.*, making it a great tow tractor.
| Accessories | Bolt-on bumpers and rear wheel guards, 24V accessories to equalize cells and extend battery life. |
|---|---|
| Body | 14-G diamond-plate steel body, tubular frame |
| Brakes | Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake, regenerative braking |
| Controller | SEPEX Electronic speed controller |
| Indicators | Battery status indicator |
| Lights | LED headlight & tail/brake light |
| Safety | Reverse alarm, deadman seat switch, horn |
| Seats | Bucket seat on slide adjusters |
| Steering | Automotive Steering Wheel |
| Suspension | Dual coil springs and shock absorber on rear |
| Transmission | Direct drive |
| Wheels | 4.8x8 LRB pneumatic tires |
| 24V | 36V | |
|---|---|---|
| Powertrain | ||
| Motor | 6 hp shunt motor | 10 hp shunt motor |
| Drive Axle | Helical gear Differential | Helical gear differential |
| Energy | ||
| Voltage | 24V | 36V |
| Battery | Four 6V-232AH batteries | Six 6V-232AH batteries |
| Charger | High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic. | High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC |
| Chassis | ||
| Equipment |
